3.6.2.3 Gain Table Update on Target Firmware

The following table provides the command syntax for gain table update on target firmware.

Table 3-45. Upgrade Gain Table on Target Firmware File
Command Syntax Upgrade_1000_gain/ Upgrade_3000_gain
Setting model
  • Upgrade_1000_gain - ATWILC1000 FW upgrade
  • Upgrade_3000_gain - ATWILC3000 FW upgrade
Example Upgarde_1000_gain

Target file will upgrade with new gain table

The following figures illustrate the example of firmware upgrade.

Figure 3-55. Console Log of Firmware Upgrade using ATWILC1000
Figure 3-56. Console Log of Firmware Upgrade using ATWILC3000
