3.3.3 HCI RX

The following table provides the command syntax for HCI RX test.

Table 3-28. Start HCI RX: HCI command only
Command Syntax MCHPRT HCI 3 X
X X refers to TX channel: 0 to 39
  • 0 – Channel 0 (2402 MHz)
  • 39 – Channel 39 (2480 MHz)
Example MCHPRT HCI 3 0

Channel 0. RX mode start

The following figure shows the example of start HCI RX test.

Figure 3-35. Console Log of HCI RX Mode
