7.2 Asynchronous Mode for Smart Card Applications

The asynchronous T=0 protocol defined by ISO 7816-3 is used for compatibility with industry-standard smart card readers. Selecting this mode requires the following power-up sequence, which complies with ISO 7816-3 for a cold reset in smart card applications.

  • Power up VCC; RST, IO-SDA and CLK-SCL are low.
  • Set I/O-SDA to Receive mode.
  • Provide a clock signal to CLK-SCL.
  • RST goes high after 400 clock cycles.

The device will respond with a 64-bit ATR code, including historical bytes to indicate the memory density within the CryptoMemory® family. Once Asynchronous mode has been selected, it is not possible to switch to Synchronous mode without powering off the device.

Table 7-1. ATR Codes for Lower Density CryptoMemory®

Device

TS

T0

TA (1)

TB (1)

TD (1)

TA (2)

T1

T2

AT88SC0104CA

$3B

$B2

$11

$00

$10

$80

$00

$01

AT88SC0204CA

$3B

$B2

$11

$00

$10

$80

$00

$02

AT88SC0404CA

$3B

$B2

$11

$00

$10

$80

$00

$04

AT88SC0808CA

$3B

$B2

$11

$00

$10

$80

$00

$08

Figure 7-2. Power-Up Sequence for Smart Card Mode
???

Smart card applications that support the Two-Wire protocol can also use CryptoMemory in Synchronous mode.
