4.4 Reset (RST)

CryptoMemory® provides an ISO 7816-3 compliant asynchronous Answer-to-Reset (ATR) sequence. When the reset sequence is activated, the device will output the data programmed into the 64-bit ATR register. When RST is low, all internal logic, access rights, and write cycles are in reset, except the Asynchronous mode activation flag. A weak internal pull-up on the RST input pad allows the device to be used in Synchronous mode without bonding RST. For synchronous-only smart card applications, an external pull-up on RST is recommended to ensure synchronous operation under any system timings or conditions. CryptoMemory does not support a synchronous ATR sequence. The RST input is not available in the plastic package options for CryptoMemory.

Figure 4-1. Connection Diagram
???
Note: While the Microchip CryptoMemory AT88SCxxxxCA is a low-voltage device (2.7V to 3.6V), its I/O buffers are designed for standard high-voltage applications (2.7V to 5.5V).
