9.1 DIN Rail/Wall Bracket Installation

This section describes the wall mounting and pole mounting instructions of the switch. The DIN Rail supplied is assembled on the product as shown in the following figure.

Figure 9-1. DIN Rail Bracket Installation
??????

To install the product on to the DIN rail, perform the following steps:

  1. Insert the button lip of the DIN-rail kit into the mounting rail.
  2. Press up the mounting rail until it snaps into place.

The following table lists the kit details supplied with the product.

Table 9-1. Din Rail Kit Details
Item DescriptionQuantity
DIN Rail-Mounting Bracket1
Screw 4

The following figure shows the wall mounting installation of the product.

Figure 9-2. Wall Mounting Installation

??????

The following table lists the kit details supplied with the product.

Table 9-2. Wall Mount Kit Details
Item DescriptionQuantity
Wall Mount2
Screw 6

For wall mounting installation, attach the wall mount to the switch using the four pan head screws and tighten the pan head screws to 1.1 Nm.
